| Brand Name: | YIWO |
| Model Number: | Tempered glass |
| MOQ: | 10 Square meters |
| Price: | negotiation |
Ultra White Anti Reflective Coating Low Iron Tempered Solar Glass
Products description:
Solar Panel Glass is a high performance low iron pattern glass with very high solar energy transmittance. When toughened, its strength and durability make it the ideal choice for crystalline silicon photovoltaic application as well as for solar thermal collectors.
Specification:
| Thickness | 3.2mm, 4mm, etc. |
| Thickness tolerance | 0.2mm |
| Further Process | cleaning, cutting, rough grinding, hole, etc. |
| Surface | Mistlite single pattern or ultra clear |
| Visible light Transmittance | 91.60% |
| swelling coefficient | 9.03×10-6/°C |
| Solar Transmittance | 92% |
| Solar reflectance | 7.40% |
| Tensile modulus | 42Mpa |
| Total solar heat gain coefficient | 92.20% |
| Shading Coefficient | 1.04% Performance varied due to different thickness |
Features:
1. better light-transmitting properties
2. low reflection
3. high strength
Application: It is widely used as water heater, solar panel, solar power generator.
Products pictures:
Packaging&Shipping:
